Current Transformer and Potential Transformer Analyzer

Analyzer is a comprehensive testing solution for both current transformers (CT) and potential transformers (PT). The instrument has a high degree of automation and high testing efficiency, making it an essential tool for transformers in the power industry.. -featured, not only satisfy the test requirements of various CTs (eg: protection type, measurement type, TP type), such as the excitation characteristics (i.e., volt-ampere characteristics), ratio, polarity, secondary winding resistance, secondary burden, ratio error and angle error, but can also be used for the tests of various PTs, including excitation characteristics, ratio, polarity secondary winding resistance, ratio error and other test of the electromagnetic unit. It provides an accurate analysis of transformer parameters, such as ratio, polarity, and accuracy class.

Applications: Used in power system protection, transformer calibration, and maintenance operations.

Analyzer Features:

Dual CT and PT testing capability
Accurate and reliable analysis
Portable and field-friendly design
Detailed reporting options for diagnostics

Product Details:

Product Code	CT PT Analyzer
Type	Transformer Analyzer
Material	Mild Steel, Plastic
Frequency Range	50 Hz To 400 Hz
CT Ratio Accuracy	0.05%
Harmonic Analysis	Up To 25th Harmonic
Phase Resolution	0.5 Min
Secondary Winding Resistance Range	0- 300 Ohm
Secondary Winding Resistance Accuracy	0.2% +/- 2 MOhm
Interface Type	USB, Bluetooth
Display Type	7-inch LCD Touchscreen
Ac Burden Accuracy	0.2% +/- 0.02VA
Phase Measurement	0° To 360°
Test Current	5 A To 100 A AC
Power Supply	Internal Battery Or AC Power
Software	Windows, IOS, Android
Additional Features	Remote Control, Automatic Calibration, Data Logging
Calibration Interval	12 Months Recommend
Exporter By	Myriad Industrial Solutions LLP
Country Of Origin	India

Frequently Asked Questions (FAQ)

Which measurement functions does this CT PT Analyzer has?

It can accurately measure the ratio difference and angle difference. The max allowable error of the ratio difference is ±0.1%, and the max allowable error of the angle difference is ±5min. It can conduct on-site testing of 0.2S class current transformers. The ratio measurement range is 1~40000. Based on the advanced frequency conversion method to test the CT/PT volt-ampere characteristic curve and 10% error curve, the maximum output AC voltage is only 180V and the AC current of12Arms (36A peak), but it can handle CT tests with inflection points as high as 60KV. Automatically provide inflection point voltage/current, 10% (5%) error curve, accuracy limit factor (ALF), instrument safety factor (FS), quadratic time constant (Ts), residual magnetization coefficient (Kr), saturation and unsaturated inductance and other CT and PT parameters.
Can the test results be saved on USB drive?

Yes
Can it be operated from Remote PC?

No
Is there any software to process/ analyze data saved in USB drive?

Yes Equipped with background analysis software to facilitate the storage, conversion, and analysis of test reports, and can be used for comparison, judgment, and evaluation of test data.
